Built for New Zealand — Designed for Life.
ACMF offers both fire rated and ultra-deluxe joinery ranges for both commercial and residential projects in New Zealand.
From the salt air of coastal homes to the high wind zones of alpine builds, New Zealand’s environment demands more from its joinery than almost anywhere else. High-performance aluminium systems aren’t just about looks — they protect against wind, water, and dust, while creating warm, quiet, and comfortable interiors all year round.
Whether you’re designing a multi-storey commercial building or a bespoke coastal home, choosing the right joinery means choosing confidence, performance, and architectural excellence that lasts.
our aluminium joinery
PREMIUM FIRE RATED RANGE
Fire Rated Aluminium doors and windows with a wide range of configurations, openings and accessories. The first accredited aluminium fire rated joinery (BRANZ assessed) in New Zealand.
Products (Fire Rated)
Windows and Doors (CS 77-FP / E 75-FP / CW 50-FP). Endless configurations.
Primary Use
Commercial and multi-residential applications requiring certified fire protection (30 / 60 min ratings), tested for safety, durability, and compliance under NZBC.
Glazing Options
Double-glazed fire-rated glass.
Maximum Height
Typically 2,700 – 3,000 mm.
Operation
Manual hinged, pivot or fixed units.
Compliance and Testing
Certified to AS/NZS and NZBC fire standards.
Wind Load Resistance
SLS 1,500 Pa / ULS 3,000 Pa — engineered for high-rise and exposed sites.
ULTRA HIGH END RANGE
For those who demand the extraordinary. Our HiFinity and MasterLine ranges represent the Rolls-Royce of aluminium joinery — combining state-of-the-art performance with seamless, luxury living.
Products (Ultra High End)
Windows and Doors (CS 77-FP / E 75-FP / CW 50-FP). Endless configurations.
Primary Use
Super luxury residential and premium commercial projects prioritising seamless aesthetics, comfort, and architectural freedom.
Glazing Options
Double or triple glazing — structural or standard.
Maximum Height
Up to 4,000 mm.
Operation
Magnetic glide, motorised automation, domotics integration.
Compliance and Testing
CE-tested to European standards (EN 10077-2, EN 1026, EN 12207-10) for energy, water, and air performance.
Wind Load Resistance
Up to 2,000 Pa + with minimal deflection (Class A ≤ 1/150). Up to 400km/hr winds.
Ten Year Guarantee
Reynaers guarantees that its systems meet the highest technical specifications and standards. We therefore issue a 10 year system guarantee. This is an insurance on the aluminium profiles, lacquer or anodization layer, as well as on the insulation.
